| Quantity: | |
|---|---|
| Model | Heat Dia | Glass Dia | Size(L*W*H) mm | Power (Kw) | Voltage(V) | Frequency(Hz) | ||
L | W | H | ||||||
| QX-B300 | Φ210 | Φ300 | 1000 | 950 | 600+400 | 3.5*4 | 220 | 50 |
| 5*4 | 220 | 50 | ||||||
Power level : 8 power level
Power supply：3.5kw*4 / 5kw*4 , 220v , single phase
Voltage fluctuation: 220v-240v
Protection grade: IPX4
Working environment: Humidity 30%-90% ;
Working temperature : -5℃-40℃
Energy efficiency: 95.1%
Power controller: Knob switch
Packing size : L1100*W1050*H1200 mm
N.W: 60kg
Certificate: CE
Warranty: 1 year
-High energy efficiency, lower noise, no pollution
-Triple dimensional radiation protective shell
-Using soft start technology, automatic alarm device
-Using the advanced technology of Germany “infineon” IGBT
-Using Japanese Alps nine gear fire-power control
-Using national patent coil, fire more uniform
-Meet IPX4 protection level with multiple protection, more secure to use
-High-strength, high-temperature resistant glass-ceramics
| Model | Heat Dia | Glass Dia | Size(L*W*H) mm | Power (Kw) | Voltage(V) | Frequency(Hz) | ||
L | W | H | ||||||
| QX-B300 | Φ210 | Φ300 | 1000 | 950 | 600+400 | 3.5*4 | 220 | 50 |
| 5*4 | 220 | 50 | ||||||
Power level : 8 power level
Power supply：3.5kw*4 / 5kw*4 , 220v , single phase
Voltage fluctuation: 220v-240v
Protection grade: IPX4
Working environment: Humidity 30%-90% ;
Working temperature : -5℃-40℃
Energy efficiency: 95.1%
Power controller: Knob switch
Packing size : L1100*W1050*H1200 mm
N.W: 60kg
Certificate: CE
Warranty: 1 year
-High energy efficiency, lower noise, no pollution
-Triple dimensional radiation protective shell
-Using soft start technology, automatic alarm device
-Using the advanced technology of Germany “infineon” IGBT
-Using Japanese Alps nine gear fire-power control
-Using national patent coil, fire more uniform
-Meet IPX4 protection level with multiple protection, more secure to use
-High-strength, high-temperature resistant glass-ceramics
